GSAP ScrollTrigger Start & End: Master Scroll Trigger Positions

Blog #14 introduced start: "top 80%". But what does that string actually mean? A ScrollTrigger position usually describes a relationship between one point on the trigger element and one point on the viewport.

gsap.from(".card", {
  y: 60,
  opacity: 0,
  duration: 0.8,
  scrollTrigger: {
    trigger: ".card",
    start: "top 80%"
  }
});

What you will learn

1. Start syntax anatomy

Read the first token as a point on the trigger and the second as a point on the scroller or viewport.

2. Trigger positions

top, center and bottom identify three useful points on the watched element.

3. Viewport positions

The same words can identify viewport points. Their role is determined by their position as the second token.

4. top top

The trigger element top meets the viewport top. While scrolling down, this generally activates later than a start line near the viewport bottom.

5. top center

The trigger top reaches the viewport center—a clear midpoint for focused sections.

6. top bottom

The trigger top reaches the viewport bottom, so activation usually occurs as the element begins entering from below. That can be useful, but may feel early for some reveals.

7. Compare top positions

8. Percentage viewport positions

A percentage is measured down the viewport: 0% is its top, 50% its center and 100% its bottom.

9. Why top 80% is common

A lower start line can begin an entrance shortly after content becomes visible. Eighty percent is not universal: element size, animation duration, reading flow, viewport size and design intent all matter.

10. center center

The trigger center meets the viewport center. This relationship can suit a large, focused interactive section.

11. bottom center

The trigger bottom reaches the viewport center, which happens later than top center for the same element.

12. bottom top

The trigger bottom reaches the viewport top. It is especially useful when reasoning about where a section's active range should finish.

13. Start position matrix

14. What is end?

scrollTrigger: {
  trigger: ".section",
  start: "top 80%",
  end: "bottom 20%"
}

start opens ScrollTrigger's active range and end closes it. An ordinary entrance tween still plays according to its own duration. End becomes especially significant for progress, callbacks, toggle behavior and later lessons about scrub and pin.

15. end: "bottom top"

The range begins when the section top meets viewport 80%, and ends when its bottom meets viewport top.

16. Start and end together

The start and end strings create a scroll-space interval. They do not describe seconds.

17. ScrollTrigger markers

scrollTrigger: {
  trigger: ".marker-section",
  start: "top 80%",
  end: "bottom 20%",
  markers: true
}

Markers reveal start, end, trigger and scroller positions during development. Keep them scoped and remove them from production.

18. A production-safe marker graphic

19. Start position playground

20. End position playground

21. Start and end playground

22. Pixel-based positions

ScrollTrigger also accepts numeric positions. A numeric value represents an absolute scroll position, while a string such as "top 300px" compares trigger top with a viewport position 300 pixels from the top.

scrollTrigger: {
  trigger: ".section",
  start: "top 300px"
}

23. Relative offsets

"top bottom-=100px" starts with a top-to-bottom relationship, then moves the scroller point 100 pixels above the viewport bottom. Use offsets deliberately and verify them on responsive layouts.

24. A relative end distance

end: "+=500" defines an end 500 pixels after the calculated start. This will become useful for scrub and pin, but it does not make an ordinary tween last 500 pixels.

25. Function-based start and end

Functions are evaluated when ScrollTrigger calculates positions, which helps when a value depends on runtime layout.

scrollTrigger: {
  trigger: section,
  start: () => "top 80%",
  end: () => "+=" + Math.max(300, section.offsetHeight)
}

26. Trigger element size matters

27. Viewport size matters

28. Practical heading reveal

The section is watched; its heading is animated.

29. Practical image reveal

The horizontal distance is reduced on small screens in the scoped JavaScript.

30. Practical card grid

Its end defines the range but does not control this stagger tween's duration.

31. A start that may feel early

top bottom can activate as an element begins entering. That is not wrong; it simply may feel early for some content reveals.

32. A start that may feel late

With top 20%, the user may scroll far into a section before its animation begins. Special designs may need it, while ordinary reading content often benefits from an earlier cue.

33. Find the right trigger position

1. Start with a reasoned value such as top 80%.
2. Temporarily inspect markers.
3. Scroll at a natural reading pace.
4. Test desktop and mobile.
5. Adjust for the actual content.
6. Disable production markers.

34. Trigger versus start

35. Start versus duration

start determines activation in scroll space. duration: 1 determines one second of time-based playback.

36. End versus duration

end is the range endpoint; duration belongs to the tween. This distinction is essential before learning scrub.

37. Start and end with a timeline

const tl = gsap.timeline({
  scrollTrigger: {
    trigger: ".start-end-timeline",
    start: "top 75%",
    end: "bottom 25%"
  }
});

tl.from(".timeline-title", { y: 40, opacity: 0 })
  .from(".timeline-card", { y: 30, opacity: 0, stagger: 0.1 });

The start and end belong to the ScrollTrigger controlling the complete timeline.

38. Multiple sections

A scoped loop can give each section its own trigger without affecting unrelated cards.

39. Dynamic content and refresh

ScrollTrigger calculates positions from layout. After a meaningful change—dynamic content, an opened accordion, a resized image, a font shift or inserted DOM—ScrollTrigger.refresh() may be appropriate. Do not call it on every scroll.

40. Resize behavior

Viewport changes affect percentages, element geometry and active ranges. ScrollTrigger handles common refresh behavior, but developers must still test real responsive layouts.

41. Common start/end mistakes

42. Debugging wrong positions

43. Main Start & End Lab

44. Lab animation lifecycle

45. Live position explanation

The lab translates syntax into plain language. Choose top center and it reports “top of element” plus “center of viewport”; choose center center and both centers must meet.

46. Scoped marker toggle

The marker checkbox is off by default. When enabled, only the lab-owned ScrollTrigger is rebuilt with markers; no other trigger is killed or changed.

47. Mini challenge

const challenge = document.querySelector(".start-end-challenge");

if (challenge) {
  const tl = gsap.timeline({
    scrollTrigger: {
      trigger: challenge,
      start: "top 75%",
      end: "bottom 25%"
    }
  });

  tl.from(challenge.querySelector(".challenge-label"), { y: 15, opacity: 0 })
    .from(challenge.querySelector(".challenge-title"), { y: 35, opacity: 0 }, "-=0.1")
    .from(challenge.querySelector(".challenge-text"), { y: 20, opacity: 0 }, "-=0.3")
    .from(challenge.querySelectorAll(".challenge-card"), {
      y: 30, opacity: 0, stagger: 0.1
    }, "-=0.2");
}

48. Quick reference

49. Cheat sheet graphic

50. Final mental model

51. Continue with Blog #16

We now understand trigger, start and end. Continue with GSAP ScrollTrigger Scrub to connect animation progress directly to scroll direction and distance.

gsap.to(".scrub-box", {
  x: 400,
  scrollTrigger: {
    trigger: ".scrub-section",
    start: "top center",
    end: "bottom center",
    scrub: true
  }
});

Continue the GSAP series

Review GSAP stagger, timelines, timeline controls, timeline position parameters, timeline + stagger, and the previous ScrollTrigger tutorial.

Frequently asked questions
